FISCHER PRO-LINE DE90 - Colour Change Assignment

5 | Operation FISCHER Mess- und Regeltechnik GmbH
86 BA_EN_DE90
5.5.6.4 Colour change assignment
Directory: \Configuration\Display\Col.ch. assignment
Level: 3
Col.ch. assignment
1 2 3 4
Channel 1
Channel 2
Channel 3
Back
H
G
U
G
E
Fig.125: Color Change Assignment
This menu is used to set the channel that controls the color change. This menu
item is not displayed for 1 channel devices.
If several channels are selected, the color change takes place as soon as one
of the channels triggers a color change. The 'triggering' channel is marked with
a dot. When re-entering the green area, the indicators are deleted.
Example Two channels are displayed on the power indicator. First, channel 2 triggers a
green-red color change. A short time later, the same colour change is triggered
by channel 1.
Measuring point 1
C1
C2 Pa
Pa68.99
Pa29.07
1 2 3 4
Pa
U
•
Triggering channel
Colour change green-red on channel 2
Measuring point 1
C1
C2 Pa
Pa120.99
Pa29.07
1 2 3 4
Pa
U
•
•
Triggering channel
Event 1:
Colour change green-red on channel 1Event 2:
Fig.126: Measured value display (color change)
