FISCHER Mess- und Regeltechnik GmbH Operation | 5
BA_EN_DE90 71
5.5.3.3.1.1 Display C3 Unit
Directory: \Configuration\Channel 3\Characteristic C3\Displ.range C3 unit
Level: 4
Displ.range C3 unit
1 2 3 4
bar
mbar
Pa
kPa
R
S
U
R
R
Fig.99: Display C3 unit
Implemented pressure units:
Unit Description
bar bar Metric and SI units
mbar milli bar
Pa Pascal
kPa kilo Pascal
MPa Mega Pascal
psi pound-force per square inch Anglo-American units (Imperial
Units)
inH₂O inch water column
mmH₂O mm Water column Historical units
mmHg mm Mercury column
The measured values of the channels and all parameters are converted into the
unit selected here. The difference is then calculated and the result displayed.
5.5.3.3.1.2 Formula C3
Directory: \Configuration\Channel 3\Characteristic C3\Formula C3
Level: 4
\...\...\...\Formula C3
1 2 3 4
Ch. 1 - ch. 2
Ch. 2 - ch. 1
Zurück
S
E
U
R
Fig.100: Formula C3
Difference = Minuend - Subtrahend
This menu determines which channel is the minuend and which channel is the
subtrahend. The difference is assigned to channel 3.
