Main Menu
432-0012-00-10 Version 100 December 2015 21
Use the joystick to navigate through the menus and select options.
Press the Menu button to exit the menus.
Note: During navigation in the OSD menu, camera zoom is disabled,
but manual focus/Auto focus is still enabled.
Some features are directly accessible from the main menu. Selecting a
menu button below invokes the action immediately and closes the
OSD menu.
Park camera: the camera drives to its predefined Park position and remains fully active (no
Stand-by) except that the video is turned off. To exit Park position and return to normal operation,
press the Home button. The camera will then return to Home position. The Park position can be
reconfigured by an admin user through the web browser interface. See “M400 Web Browser
Interface” on page 30.
InstAlert/Exit InstAlert mode: When the camera is placed in InstAlert mode, a special
search palette is invoked so that a set percentage of the hottest temperatures in the image are
highlighted in Red-Orange shades, while colder temperatures are all in shades of gray. Especially
useful for locating people or running boats in the dark. After invoking the mode, pressing the Menu
button will show the InstAlert settings menu. The Highlight setting controls the percentage of the
hottest temperatures to display in Red-Orange.
IceAlert/Exit IceAlert mode: Conversely to InstAlert mode, when the camera is placed in
IceAlert mode, a special search palette is invoked so that a set percentage of the coldest
temperatures in the image are highlighted in Blue-Green shades, while warmer temperatures are
all in shades of gray. Especially useful for locating ice in the dark. After invoking the mode,
pressing the Menu button will show the IceAlert settings menu. The Highlight setting controls the
percentage of the coldest temperatures to display in Blue-Green.
