432-0012-00-10 Version 100 December 2015 22
Surveillance: When the camera is in surveillance mode, it pans continuously left and right,
until it is taken out of surveillance mode or until the JCU II is used to move the camera. The
camera does not automatically resume panning; enable surveillance again by pressing a User
button (if it is programmed to enable this mode) or selecting it in the main menu.
Surveillance settings… When Surveillance settings is selected from the Setup menu or the
Menu button on the JCU II is pressed when in Surveillance mode, the following OSD menu is
shown.
Scan Width: In surveillance mode, the Scan Width determines the range of horizontal azimuth
(pan) covered by each scan. The choices are:
Custom: The camera scans from approximately 20
o
left and right of center
(40
o
total).
Small: The camera scans from approximately 20
o
left and right of center
(40
o
total).
Medium: The camera scans from approximately 40
o
left and right of center
(80
o
total).
Large: The camera scan covers 80
o
to the left and right of center
(160
o
total). The default scan width is wide.
Note: The center of the scan pattern is determined by the direction the camera is pointing when
surveillance is enabled. The scan pattern is not centered about the home position, unless the
camera is in the home position when surveillance is enabled.
Scan Speed: In surveillance mode, the scan speed determines how quickly the camera scans
back and forth. The choices are fast, medium, and slow.
The scan speed is affected by the zoom state (if the camera is zoomed in, it scans at a slower
rate). The default scan speed is slow; try all three settings to determine which is best for any
situation.
NMEA: Select this option to enable or disable the processing of messages using the NMEA
interface. The factory default setting is disabled. All messages are ignored when NMEA Mode is
disabled even if the specific message types are enabled. See “NMEA Settings” on page 29.
