System Specifications
432-0012-00-10 Version 100 December 2015 57
System Specifications
Table 6.3 lists details about physical characteristics, power usage, and environmental features of
the M400 camera.
Troubleshooting Tips
This section includes information that may help with common issues that may arise during
operation of the M400 system.
Video not displayed on monitor
The camera will not display video if it is in standby mode. Power cycle the camera and allow the
system to complete the bootup cycle prior to JCU II connection. Ensure the JCU II is assigned to
TABLE 6.3 Specifications
Physical Characteristics
Camera Size 32.4 cm (12.75 in) diameter by 46 cm (18.1 in) tall
Camera Weight 12.22 kg (27 lb), depending on the camera model
Joystick Size 9.1 X 14.2 X 8.13 cm (3.6 X 5.6 X 3.2 in)
7.4 cm (3 in) above platform including joystick
Joystick Weight 0.45 kg (1 lb)
Power
Camera Input Power 24 Vdc, 2.5 A typical, 5.5 A max
12 Vdc, 5 A typical, 11 A max
Absolute range 12 Vdc to 32 Vdc
JCU II Input Power
Power over Ethernet (PoE) per IEEE 802.3af
Consumption 50 W nominal, 132 W maximum
Environmental
Operating temperature
range
–20 °C to +55 °C (–4 °F to +131 °F) per IEC 60945
Storage temperature range –50 °C to +80 °C (–58 °F to +176 °F)
Automatic Window defrost Standard
Sand/dust IEC 60945
Water Ingress IP X6
Shock 15 g vertical, 9 g horizontal
Vibration IEC 60945
Lightening Protection IEC 60945
Salt Mist IEC 60945
Wind 100 knot (115 mph)
EMI IEC 60945
