432-0012-00-10 Version 100 December 2015 56
NMEA TTM
Message
Receiving NMEA messages using the NMEA Tracked Target
Message (TTM) sentence format has been enabled; this is also
known as radar tracking
Power down
The camera is shutting down.
Scene: Night One of four scene presets (automatic gain control settings)
optimized for use on the open water at night.
Scene: Docking One of four scene presets (automatic gain control settings)
optimized for use when the boat is docking at night.
Scene: Day One of four scene presets (automatic gain control settings)
optimized for use on the open water during the day.
Scene: Contrast One of four scene presets (automatic gain control settings)
optimized for providing visibility to small moving objects.
Vertical
Stabilization
Indicates the gyro stabilization setting is vertical only (point
mode), which improves camera image stability while keeping
the camera pointing in the same position relative to the vessel
as it turns.
Vertical and
Horizontal
Stabilization
Indicates the gyro stabilization setting, which improves camera
image stability, while keeping the camera pointing in the same
direction even as the vessel turns.
Zoom scale Shown to indicate the progress of the zoom position of the
active camera.
