Product description
Figure 9, Coin verifier checks that a coin is valid and determines its type.
If a coin is valid, the movable coin ramp moves out of the way so the coin falls into
the escrow. If the coin is invalid, the movable coin ramp guides it, via the scrap
channel, into the coin return cup instead.
On the right side of the coin verifier (as seen from the front of the terminal) there is
a lid.
Important:
The coin verifier can be opened manually for inspection, emptying, and
cleaning.
The coin verifier is an industry standard 3.5” electronic device programmed to
recognize up to 16 types of coins from optional currencies. For each coin type
recognized a unique code is sent to the CPU board.
Flowbird provides pre-programmed coin verifiers for all countries where the
terminals are sold, but clients can also program the modules themselves if
necessary. Contact Flowbird for further information about coin verifier
programming.
