Page 21CWT Compact S4 Touch Installation & Maintenance Manual for CWT 1.0-0Issue 3
Product description
CWT018 R1
Trap door
Barrier plate
Figure 8, Metal object stuck in the coin slot.
If an object, or part of an object, remains in the coin slot opening as shown in the
figure above, the barrier plate will stop against this object but will close as soon as
the object is removed.
Important:
The function of the coin system may be interrupted if the terminal leans too much
in any direction.
If an object, or part of an object, is inserted and prevents the trap door from
closing, this will be detected. The coin system will try to remove the object, if it
doesn’t succeed the terminal will send an alarm to WebOffice.
4.1.1.2
Coin verifier
The coin verifier reveals if valid coins have been used. The verifier also includes
sophisticated electronics for determining what type of coin is passing.
