Page 76CWT Compact S4 Touch Installation & Maintenance Manual for CWT 1.0-0Issue 3
Corrective maintenance
Assembly
Install in reverse order.
8.3 Printer replacement
Gebe GTP4672 replacement
No specific actions needed
See Printer mounting for instruction how to dismount and mount the printer
·
Remove any paper left in the printer
·
disconnect all the cables
·
unlock and lift of the printer shelf
·
dismount the printer from its shell
·
replace the new printer in reversed order
8.4 Coin unit replacement
Removal
1. Disconnect all cables from the coin unit. The number of cables depends on the
terminal model and configuration.
2. Unscrew the two screw nuts, one on each side of the Coin Return opening.
3. Remove the coin unit.
