Corrective maintenance
Install in reverse order.
8.6 Card reader replacement
Replacing the card reader depends on the model installed.
Chip Card Reader
Chip card readers are often equipped with tamper switches on both the card
reader and pin pad. Partly unscrewing the reader may already trigger the tamper
switch making the reader useless. If this is the case, the reader must be sent back
to the supplier to reset the switch.
Reference:
How to safely dismount and mount a reader is described in the reader's
installation guide: e.g. 3C XENTEO ECO Mounting instructions CWT C with CPU
board 0501-E0150
MagStripe readers
· Disconnect the cable
· Unscrew the reader
· Mount the new reader
· Connect the cable
8.7 Display Module replacement
CWTC S4 Touch Display Panel gives an exploded view drawing of the touch
panel without the display unit.
CWTC S4 Touch Display unit gives an exploded view drawing of the display
unit itself.
The display module consists of the following parts:
