Page 64CWT Compact S4 Touch Installation & Maintenance Manual for CWT 1.0-0Issue 3
Daily operation
Removing the coin box
1. Open the vault door with the appropriate key.
2. Turn the opening knob clockwise to the horizontal position. This closes the
collection hatch and releases a catch that holds the box in position in the vault.
3. Pull the coin box out. A collection ticket will be printed.
Warning:
The coin box may be heavy depending on the amount of coins in it
Emptying the coin box
1. Turn the collection lock clockwise with the appropriate key. The same key
combination is usually used for all coin boxes.
2. Pull the emptying hatch out completely. This will empty the box of its contents
and activate the internal mechanism.
3. Push the emptying hatch in. The hatch can be pushed back in only if it has
previously been pulled out completely.
4. Turn the collection lock counter clockwise and remove the key.
Inserting the coin box
1. Insert an empty coin box.
2. Turn the opening knob counter clockwise to its vertical position. This locks the
box into position in the vault and opens the collection hatch.
Important:
If the knob is accidentally turned to the horizontal position at this point, the
