Bit Number Modbus Bit Address MX/DDC
139 138 Channel A fault
140 139 Channel B fault
141 140 Open torque switch fault
142 141 Close torque switch fault
143 142 Valve operated manually fault
144 143 Phase error
145 144 Open inhibit active
146 145 Close inhibit active
147 146 Not used
148 147 Not used
149 148 One or more phases is missing
150 149 Reverse phase sequence is occurring
151 150 ESD conflict
152 151 Inhibit conflict
153 152 Use in local/stop (input must be set for CSE and enabled)
154 153 Not used
155 154 Network emergency shutdown (ESD) is active
156 155 Local emergency shutdown is active
157 156 Field unit microprocessor has reset since the last poll
158 157 MX in stop mode
159 158 Opening in local mode
160 159 Closing in local mode
161 160 Close contactor (interlocked)
162 161 Open contactor (interlocked)
163 162 S1 or R1 (opt)
164 163 S2 or R2 (opt)
165 164 R3 (opt)
166 165 R4 (opt)
167 166 R5 (opt)
168 167 R6 (opt)
169 168 R7 (opt)
170 169 Network relay
171 170 R8 (opt)
172 171 Not used
173-176 172-175 MOV series (0-1, A=9)
177 176 Remote switch
178 177 Thermal overload
179 178 Open torque switch
180 179 Open limit switch
181 180 Close torque switch
182 181 Close limit switch
183 182 Not used
184 183 Not used
185 184 User Input 0
186 185 User Input 1
187 186 user Input 2
