ST51A/ST75A/ST75AV Mass Flow Meters OPERATION
Fluid Components International LLC 49
ST51A/ST75A/ST75AV HART Device Specific Commands
In the HART protocol all commands defined as Manufacturer Specific, or Device Specific start at command 128. Use the device specific
commands to setup and configure the ST51A/ST75A/ST75AV instrument via HART.
Table 14 below summarizes the instrument’s HART Device Specific command set and the data associated with each command.
Table 14 – HART Device Specific Commands
Command 137: Read Totalizer And Rollover Values
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–3
Float
Totalizer
4–7
Integer
Rollover
Response Codes:
See Table 16, page 53, for response code list.
Command 138: Read Totalizer State
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0
Unsigned-8
Totalizer State: 0 = OFF; 1 = ON
Response Codes:
See Table 16, page 53, for response code list.
Command 139: Write Totalizer State
Byte
Format
Description
Request Data Bytes
0
Unsigned-8
Totalizer State: 0 = OFF; 1 = ON
Response Data Bytes
0
Unsigned-8
Totalizer State: 0 = OFF; 1 = ON
Response Codes:
See Table 16, page 53, for response code list.
Command 140: Read Device Information
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0–9
Bits
Device CO
10–19
Bits
Device Serial Number
19–22
Bits
Device Software Version
Response Codes:
See Table 16, page 53, for response code list.
Command 141: Write Totalizer Reset
Byte
Format
Description
Request Data Bytes
0–1
Unsigned-16
Reset Key = 0xABCD
Response Data Bytes
0–1
Unsigned-16
Reset Key = 0xABCD
10–19
Bits
Device Serial Number
19–22
Bits
Device Software Version
Response Codes:
See Table 16, page 53, for response code list.
Command 145: Read Customer Engineering Units
Byte
Format
Description
Request Data Bytes
None
Response Data Bytes
0
Unsigned-8
Units Code for Flow
1
Unsigned-8
Units Code for Temperature
2
Unsigned-8
Units Code for Totalizer
Response Codes:
See Table 16, page 53, for response code list.
