24-1
Chapter 24
Setting up the Analyzer
Introduction
The Analyzer offers many measuring functions. These functions are preset in a way that
the best possible representation of measuring results is obtained in almost all
circumstances. However - if desired - the user can make personal setups that meet
specific requirements. This chapter explains what setups can be made and where they can
be found in the menus. Some setups will be explained step by step.
Initial setups.
When you power the Analyzer for the first time, after a Factory Default, or if it has been
disconnected from all power sources, you will have to adjust a number of general settings
that match your local situation. The table below gives an overview:
Setting Preset Value
Information language English
Nominal Frequency 60 Hz
Nominal Voltage 120 V
Phase Identification A, B, C
Phase Colors A/L1-B/L2-C/L3-N-Ground Black-Red-Blue-Gray-Green
Date* + Date Format Month/Day/Year
Time* 00:00:00
* will not be reset after a Factory Default
Starting in the LANGUAGE screen use the up/down arrow keys to highlight the
preferred language, press ENTER and confirm the banner message to set the language.
Press F5 – NEXT to set the next initial setup item.
When ready with setup of the parameters in the table, the screen shown in Figure 24-1 is
displayed. This screen gives you access to all adjustments of the Analyzer.
