Fluke 434-II/435-II/437-II
Users Manual
17-2
e
ENTER
Flicker is characterized by: instantaneous flicker Pinst, short term severity Pst (measured
over 1 min for fast feedback), short term severity Pst (measured over 10 min) and a long
term severity Plt (measured over 2 hours). Also related data such as half cycle rms for
voltage (Vrms ½), current (Arms ½) and frequency are measured.
Available function keys (popup Meter screen must be off):
F1
Up/down arrow keys are assigned to scroll Meter screen.
F3
Access to Trend screen. For description see below.
F4
Access to Events menu. The number of events that occurred
is shown.
F5
Switch between HOLD and RUN of screen update.
Switching from HOLD to RUN invokes a menu to select
immediate (NOW) or TIMED start time which allows you
to define start and duration of the measurement.
Trend
To access Flicker Trend screen:
f
F3
The parameters in the Meter screen update over time. They are recorded whenever the
measurement is on. Trend displays the changes in these values over time. All values in
the Meter screen are recorded, but the Trends from each row in the Meter screen are
displayed one at a time. The arrow keys are assigned to scroll the trend screen. The Trend
display may consist of 6 screens.
Available function keys:
F1
Up/down arrow keys are assigned to scroll the Trend screen.
F2
Access to cursor and zoom menu.
