Specifications
Electrical Measurements27
27-9
Transient capture Measurement Range Resolution Accuracy
Volts
cursor reading
rms reading
± 6000 Vpk
10 … 1000 Vrms
0.1 V
0.1 V
± 15% of cursor reading
± 2.5% of Vnominal
Minimum detect duration 5 µs
Sampling rate 200 kS/s
WIRING COMBINATIONS
1Ø + NEUTRAL Single phase with neutral
1Ø SPLIT PHASE Split phase
1Ø IT NO NEUTRAL Single phase system with two phase voltages without neutral
3Ø WYE Three phase four wire system WYE
3Ø DELTA Three phase three wire system Delta
3Ø IT Three phase system without neutral WYE
3Ø HIGH LEG Four wire three phase Delta system with center tapped high leg
3Ø OPEN LEG Open delta three wire system with 2 transformer windings
2-ELEMENT Three phase three wire system without current sensor on phase L2 / B (2 watt
meter method)
2½-ELEMENT Three phase four wire system without voltage sensor on phase L2 / B
INVERTER
EFFICIENCY
dc voltage and current input with ac output power (automatically displayed and
selected in Inverter Efficiency mode)
