List of Tables
TABLE TITLE PAGE
1-1. Accessories Included with each Signal Generator 1-3
1-2. Optional Accessories 1-3
1-3. 6080A/AN Specifications 1-4
1-4. Typical Signal Generator Performance 1-9
2-1. Frequency Coverage Bands 2-3
3-1. Front Panel Controls for AM Calibration Procedure 3-5
3-2. Remote Programming Commands for AM Calibration Procedure 3-7
3-3. Front Panel Controls for FM Calibration Procedure 3-8
3-4. Remote Programming Commands for FM Calibration Procedure 3-10
3-5. Front Panel Controls for Level Calibration Procedure 3-12
3-6. Remote Programming Commands for Level Calibration Procedure 3-14
3-7. Front Panel Controls for Reference Oscillator Calibration Procedure 3-15
3-8. Remote Programming Commands for Reference Oscillator
Calibration Procedure 3-17
4-1. Recommended Test Equipment 4-2
4-2. High-Level Accuracy Test Conditions 4-7
4-3. High-Level Accuracy Test Conditions Sample 4-8
4-4. Modulation Tests Requirements 4-17
4-5. AM Test Conditions 4-19
6-1. Module Exchange Assemblies 6-4
6-2. General Self-Test Results 6-8
6-3. Digital Test Results 6-9
6-4. AM Test Conditions 6-9
6-5. FM Tests 6-10
6-6. Phase Modulation Test Conditions 6-10
6-7. DC FM Tests 6-10
6-8. Coarse Loop Tests 6-11
6-9. Sub-Synthesizer Tests 6-11
6-10. Sum Loop Tests 6-11
6-11. RF Output Tests 6-12
6-12. Pulse Modulator Tests 6-12
6-13. Filter Tests 6-13
6-14. Status Signals and Codes 6-13
6-15. Parameter Settings of Diagnostic States 6-14
ix
(continued on page x)
