Section 6E
Frequency and Phase Modulation
FM/øM FAULT TREE 6E-1.
The FM/øM Fault Tree, Figure 6E-1, is the starting point for troubleshooting
FM/øM problems.
6E-1
Figure 6E-1. FM/øM Fault Tree
