Fluke 6080A - Table of Contents

Table of Contents
SECTION TITLE PAGE
1 INTRODUCTION AND SPECIFICATIONS 1-1
1-1. INTRODUCTION 1-1
1-2. UNPACKING THE SIGNAL GENERATOR 1-1
1-3. SAFETY 1-2
1-4. ACCESSORIES 1-3
1-5. SIGNAL GENERATOR SPECIFICATIONS 1-3
2 THEORY OF OPERATION 2-1
2-1. INTRODUCTION 2-1
2-2. GENERAL DESCRIPTION 2-1
2-3. Front Panel Section 2-2
2-4. Upper/Lower Module Sections 2-2
2-5. Rear Panel Section 2-2
2-6. FUNCTIONAL DESCRIPTION 2-2
2-7. Frequency 2-2
2-8. Frequency Modulation 2-4
2-9. Phase Modulation 2-4
2-10. Output/Level Control 2-5
2-11. Amplitude Modulation 2-5
2-12. Pulse Modulation 2-5
2-13. Internal Modulation Oscillator 2-6
2-14. Power Supply Description 2-6
2-15. DIGITAL CONTROLLER SOFTWARE DESCRIPTION 2-6
2-16. User Interface 2-6
2-17. Calibration/Compensation Memory 2-7
2-18. Self-Test 2-7
2-19. Status Signals 2-7
3 CLOSED-CASE CALIBRATION 3-1
3-1. INTRODUCTION 3-1
3-2. Front Panel Calibration 3-2
3-3. Remote Calibration 3-2
3-4. Calibration Data 3-3
3-5. AM CALIBRATION 3-4
3-6. Front Panel AM Calibration Procedure 3-4
3-7. Remote AM Calibration Procedure 3-6
i
(continued on page ii)
