INTRODUCTION AND SPECIFICATIONS
Table 1-3. 6080A/AN Specifications (cont)
1-5
SPECTRAL PURITY (CW ONLY)
NON-HARMONIC SPURIOUS < -100 dBc for offsets greater than 15 kHz.
NOTE
Fixed frequency spurs are <-100 dBc or < -140 dBm, whichever is larger.
NOTE
dBc refers to decibels relative to the carrier frequency, or in this case, relative to the signal level.
HARMONICS / SUBHARMONICS < -30 dBc for levels < +7 dBm.
POWER LINE SPURIOUS < -40 dBc within ± 15 kHz of carrier.
RESIDUAL FM (RMS in
0.05- to 15-kHz band) < 20 Hz
SSB PHASE NOISE < -130 dBc/Hz @ 20 kHz offset for Frequency
< 512 MHz
< -124 dBc/Hz @ 20 kHz offset for Frequency
> 512 MHz
RESIDUAL AM (in 0.05- to 15-kHz Band) <-80 dBc. (.01%)
AMPLITUDE MODULATION (3-DIGIT DISPLAY)
(Amplitude < 0 dBm)
INDICATED DEPTH RANGE ....................... 0 to 99.9%.
RESOLUTION 0.1%.
ACCURACY (0 to 90%) + 7% AM at 1 kHz rate
DISTORTION < 5% Total Harmonic Distortion (THD)
@ 50% AM (rates = 0.1, 1, 10 kHz)
BANDWIDTH (3 dB) 10 Hz to 100 kHz
INCIDENTAL FM < 200 Hz at 1 kHz rate, 50% AM.
FREQUENCY MODULATION (3-DIGIT DISPLAY)
DEVIATION RANGES 0 to 999 Hz
1 to
9.99
kHz
10 to
99.9
kHz
100 to 999 kHz
1 to 4 MHz
EXT RATES DC to 100 kHz
