INTRODUCTION AND SPECIFICATIONS
Table 1-4. Typical Signal Generator Performance (cont)
ELECTROMAGNETIC COMPATIBILITY.. The radiated emissions induce < 1 μV into a 1-inch
diameter, 2-turn loop, 1-inch from any surface as
measured into a 50-ohm receiver.
COMPLIES WITH THE FOLLOWING STANDARDS:
CE03 of MIL-STD-461B (Power and interconnecting leads), 0.015 to 50 MHz.
RE02 of MIL-STD-461B (14 kHz to 10 GHz).
FCC Part 15 (J), class A.
CISPR 11.
SIZE Width Height Depth
43 cm
13.3
cm
59.7
cm
17 in
5.25
in
23.5
in
POWER 115/230 VAC, ±10% 50, 60, & 400 Hz ±10% < 250 VA
WEIGHT < 27 kg (60 Ibs).
SUPPLEMENTAL CHARACTERISTICS
The following characteristics are provided to assist in the application of the signal generator and to
describe the typical performance that can be expected.
FREQUENCY SWITCHING SPEED .......... < 100 ms to be within 100 Hz.
AMPLITUDE SWITCHING SPEED ........... < 100 ms to be within 0.1 dB.
AMPLITUDE RANGE Programmable from +20 to -147.4 dBm. Fixed-range,
selected by special function, allows for more than 12
dB of vernier without switching the attenuator.
EXTERNAL MODULATION Annunciators indicate when a 1V peak signal is
applied, ±2%, over a 0.02- to 100-kHz band.
IEEE All controls except the power switch and the internal/
external reference switch are remotely programmable
via IEEE-488 Interface (Std 488.2-1987). All status
including the option complement are available
remotely.
EXTERNAL REFERENCE LOCK RANGE ± 10 ppm
PULSE MODULATION
PULSE DELAY OFF/ON 80 ns typ
ON/OFF 65 ns typ
1-17
