1. Prior to Starting
1-1. Overview
The MFR-6000 is a multi-format routing switcher that supports 12G-SDI, 3G-SDI, HD-SDI, SD-SDI,
and ASI signals. Inside the 13U case a matrix of up to 144 inputs/ 144 outputs can be configured. It
supports various functions such as the capability of linking multiple units, tally connections with
peripheral devices, and automatic source name tracking, to allow the units to be the core product in
A/V systems.
1-2. Features
 Support for 12G-SDI, 3G-SDI, HD-SDI, SD-SDI, and ASI signals with automatic signal
recognition that enables operation without concern for the type of signal. Changing the
input/output card enables support for SD-SDI signals.
 One routing switcher can be virtually partitioned to build any theoretical hierarchy, which
creates possibilities for use in various operating forms.
 Various crosspoint control functions such as Salvo, Take, Link, Level operation, and Chop
 Tally linking with FOR-A’s video switchers (HANABI Series) and multi viewers. Source name
displayed on video switchers and multi viewers can be simultaneously changed according to
crosspoint switches on MFR routers by TSL or Harris protocol, which also enables linkage to
other companies' products.
 Built-in webserver for remote control through a web browser
 SNMP support enabling SNMP monitoring system configuration
 Status monitoring for power supply, fan, CPU, SDI input/output, etc.
 CPU board redundancy allowing monitoring of primary CPU board operation via the
secondary board. Real time and smooth switching over to secondary board without down time
in case of malfunctions, as well as stable remote control operation supported by network
redundancy
 Power unit redundancy for stable power supply against power unit failure or power supply
troubles
 Main unit front display of settings and alarms enabling the main unit to take over operation in
the event a remote environment goes down.
 Matrix partition and level setting capabilities support a flexible control environment (maximum
of 128 units total including main unit)
 Remote control panel connectivity for configuring a huge control panel
 Interface expansion unit (MFR-GPI) for additional 128 (32 x 4) GPI/O and 4 serial ports (9-pin
D-sub, male)
 MFR-TALM Tally Manager Unit is designed specifically to manage tally and signal name data
in the MFR system and exchange of this data with external devices such as video switchers,
multiviewers, etc. The unit performs the task of tally data computation, ordinarily undertaken
by the MFR main unit, to accelerate the task.
 Allows conversions between 12G-SDI and Quad Link 3G-SDI signals, and between 2SI and
SQD, by installing optional MFR-2SDIGB and MFR-2SDOGB (Gearbox feature built-in) cards.
