8. Specifications and Dimensions
8-1. Unit Specifications
8-1-1. MFR-6000
Video Formats
12G-SDI
2160/59.94p, 2160/50p
3G-SDI
1080/60p, 1080/59.94p, 1080/50p
HD-SDI
1080/60i, 1080/59.94i, 1080/50i,
1080/30p, 1080/30PsF, 1080/29.97p, 1080/29.97PsF,
1080/23.98p, 1080/23.98PsF, 1080/25p, 1080/25PsF,
1080/24PsF, 1080/24p,
720/60p, 720/59.94p, 720/50p
SD-SDI
525/60, 625/50
Matrix Size
Min. 9 x 9 to Max. 144 x 144 (Expandable on a 9-channel basis)
Number of input slots: 16
Number of output slots: 16
Video Input
MFR-9SDI12G
SDI Input Card: 75 ohm, BNC x 9 (16 cards Max.)
Complies with the following standards (75Ω BNC)
- SMPTE ST 2082-10 (12G-SDI)
- SMPTE424M (3G-SDI)
- SMPTE292M (HD-SDI)
- SMPTE259M (SD-SDI)
- DVB-ASI
Cable Equalization
12G-SDI: 100 m (L-5.5CUHD cable)
3G/HD-SDI: 100 m (5C-FB cable)
MFR-8SDIEX
SDI Input Card: 75 ohm, BNC x 8 (16 cards Max.)
Complies with the following standards (75Ω BNC)
- SMPTE424M (3G-SDI)
- SMPTE292M (HD-SDI)
- SMPTE259M (SD-SDI)
- DVB-ASI
Cable Equalization
3G/HD-SDI: 100 m (5C-FB cable)
SD-SDI: 200 m (5C-2V cable)
MFR-2SDIGB
SDI Input Card
BNC x 2 (12G-SDI or 3G-SDI)
BNC x 6 (3G-SDI)
Complies with the following standards (75Ω BNC)
SMPTE ST 2082-10 (12G-SDI)
SMPTE ST 425-5 (Quad Link 3G-SDI)
I/O delay selection
Delay (H) (0.3H-1H), 1 frame, 1 frame+ Delay (H)
Video Output
MFR-9SDO12G
SDI Output Card: 75 ohm, BNC x 9 (16 cards Max.)
Complies with the following standards (75Ω BNC) (Auto reclocking)
- SMPTE ST 2082-10 (12G-SDI)
- SMPTE424M (3G-SDI)
- SMPTE292M (HD-SDI)
- SMPTE259M (SD-SDI)
- DVB-ASI
Cable Equalization
12G-SDI: 100m (L-5.5CUHD cable)
3G/HD-SDI: 100m (5C-FB cable)
