2-3. SDI Input/Output Cards
SDI input/output cards are available to install slots shown on the table and figure below.
► See Sec. 2-1-1. “Matrix Size Chart” for details.
Slot No
Input/ Output Cards
01-04
(Input 1-4)
MFR-9SDI12G
MFR-8SDIEX
MFR-2SDIGB
05-12
(Output 1-8)
MFR-9SDO12G
MFR-8SDOEX
MFR-2SDOGB
13-16
(Input 5-8)
MFR-9SDI12G
MFR-8SDIEX
MFR-2SDIGB
17-20
(Input 9-12)
MFR-9SDI12G
MFR-8SDIEX
MFR-2SDIGB
21-28
(Output 9-16)
MFR-9SDO12G
MFR-8SDOEX
MFR-2SDOGB
29-32
(Input 13-16)
MFR-9SDI12G
MFR-8SDIEX
MFR-2SDIGB
2-3-1. MFR-9SDI12G
1
2 3 4 5 6 7 8 9
BNC x 9 inputs (12G/3G/HD/SD-SDI and ASI)
Set up input signals in the Web-based Control Software as shown below.
 Source Name
Open the [Web-based Control: ROUTER SYSTEM SETTINGS - Source Name page].
This page allows you to change source names displayed on Remote Controllers or other
devices.
 Source Assignment
Open the [Web-based Control: ROUTER SYSTEM SETTINGS - Source Assignment page].
This page allows you to assign physical inputs to logical input channels.
