Franke Evolution - Common Outlet; Outlet Switch; Temp. Autosteam; Temp. Autosteam Pro

Franke Kaffeemaschinen AG
TD-100228 A.doc page 16 / 33
24 Temp. Autosteam option Autosteam Menu point 1.30 – AS-Yes
M: 60°C [0-99]
(Celsius)
24 Temp. Autosteam Pro option Autosteam Pro Menu point 1.30 – AS-Pro
M: 60°C [0-99] Temperature setting for Steam
F: 45°C [0-99] Temperature setting for Steam/Air
C: 3 [0-6] Number of steam shots for compression
(Celsius)
25 Common outlet
+ 00s [+ / - 50] 0 for milk with coffee
(Seconds) Minus time for milk befor coffee
Plus time for milk after coffee
26 Outlet switch option
no [yes / no] Yes: e.g. pot outlet with ‘steam pipe’
Only for coffee products
27 Pressure
70PWM % [25-90] With too little PWM the BU motor lacks the
(Pulse width modulation) required force to overcome the resistance of
the piston gasket (not enough voltage)
30 % 70 %
24 V 24 V
0 V 0 V
1 2 time (s) 1 2 time (s)
28 Pressure time
1.0s [0.0-5.0] Pressing ground coffee
(Seconds in steps of 0.1s)
29 BU-open
0.00s [0-25] Opening the brewing unit for the brewing
(Seconds in steps of 0.01s) process
Warning: Pay attention to piston position!
