Franke Evolution User Manual

Franke Kaffeemaschinen AG
TD-100597.doc 20 / 20
6.1 Evolution in accounting mode
6.1.1 Prerequisites
Ø Evolution software version 1.4 or higher, or Evolution OEM software version 16.4 or higher
Ø Accounting system printed board for the Evolution chocolate dispenser, article no. 1T 311’445
Ø Accounting board cable 1T 311’466
6.1.2 Troubleshooting
Should a malfunction occur, the inputs and outputs can be verified using the following table:
The accounting operation must be deactivated on the Evolution to be able to carry out this test
and the “ready for operation” LED on the chocolate dispenser must be illuminated.
Set-up
Coffee machine
"8 Check Inputs"
Idle state Aktive signal
(Chocolate product button
is pressed)
"8.7 Choco Input 1" On Off
"8.8 Choco Input 2" On Off
Set-up
Coffee machine
"7 Check Outputs"
Idle state Aktive signal
(Choco product is drawn)
"7.19 Choco Out1" Off On
"7.20 Choco Out2" Off On
6.2 Sinfonia in accounting mode
6.2.1 Prerequisites
Ø Sinfonia software version 1.3 or higher, or Sinfonia OEM software version 15.1 or higher
Ø Accounting system printed board for the Evolution chocolate dispenser, article no. 1T 311 445
Ø Accounting board cable 1Y 320 532
