Franke Evolution User Manual

Franke Kaffeemaschinen AG
TD-100228 A.doc page 21 / 33
7. Check Outputs
Off Activate output with the ‘+’ button
On Deactivate the output with the ‘-‘ button
1 K3 Coffee
2 K2 HW/steam
3 K7 Water pump
4 K6 Grinder left
Warning: Overfilling of the brewing unit!
5 K4 Grinder right
6 Y4’ V CW mix
7 Y5 V feed
8 Y3 V breakfast
9 Y30 Cappu clean.
10 Y31/37 Cappu air
11 Y20 Cappu steam
12 Y33 V Water main
13 Y4 Tea valve
14 Y1 Brew valve
15 Y6 Steam valve 1
16 Y6’ Steam valve 2
17 Milk Bit 1 Bit 1 = fast pump
18 Milk Bit 2 Bit 2 = medium fast pump
19 Choco out 1
20 Choco out 2
Milchtabelle
Bit 1 Bit 2 Function on milk print Evolution temperture level
0 0 Pump does not run -
1 0 Fast pump (P1) Level 1 (no steam) / 2 (with steam)
0 1 Medimum fast pump (P2) Level 3 (with steam)
1 1 Slow pump (P3) Level 4 (with steam)
0 = Off / 1 = On

Franke Evolution Specifications

General

Power Supply	220-240 V
Water Supply	Tank
Water Connection	No
Material	Stainless Steel
Programs	Espresso, Coffee, Cappuccino, Latte Macchiato, Hot Water
Display	Yes
Milk System	Integrated
