Franke Evolution User Manual

1 = Replace
2 = Clean; control (replace when needed)
3 = Visual inspection; adjust (replace when needed) 6 Mth. 12 Mth. 36 Mth.
Group Article Amount Description Basic Top /20000 /40000 /120000
Boiler 1T 310 403 1 Boiler coffee "Ecopower" x - 3 2
1T 310 000 1 Heating element Boiler x x - 3 1
1T 310 001 1 Boiler Tea Steam,Coffee x - 3 2
1T 310 404 1 Tea-/Steamboiler Ecopower x - 3 2
1T 310 271 1 Heating element 3000W/230V AC x - 3 1
1T 311 717 1/2 O-ring 44.4x3.53 Viton x x - 3 1
1T 311 718 1/2 washer D=50.8/55.6x3 x x - 3 2
1Y 320 987 1 Pressure switch x x 3 3 1
1H 327 826 1 Manometer 6bar x x 3 3 3
BK 320 972 1 Level probe 93.5mm x 2 2 1
BK 320 973 1 Level probe 75mm x 2 2 1
10 296 250 2/4 Safety-thermostat x x - 3 1
1T 310 026 1 Safety valve x x - 1 1
1T 311 294 1 Pipe to press switch E/EII x x 3 3 -
1T 310 124 2 Bleed connection x x - 2 2
BK 310 601 1 Mix valve complete x - 3 2
Brew group 1T 310 411 1 Brewing Group 99, compl. x x 3 2 1
1L 301 007 2 O-Ring 6.07x1.78 to outlet x x - 1 1
1T 310 398 2 Locking nut M5 BN6783 x x - 1 -
1T 310 316 2 EFFBE Rubberspring x x - 1 -
BK 311 429 1 Lubrication felt for Brew unit 99 x x - 1 -
1T 310 302 1 Driving Motor with Spindle x x - 2 -
1T 310 422 2 O-Ring 9,19 x 2,62 x x - 1 -
BK 310 685 1 sealing kit for guide shaft x x - 2 -
1T 310 295 1 Water sieve x x - 1 -
1T 310 283 1 Ejecting piston x x - 2 -
BK 310 155 1 O-Ring D 37,77x2,62 x x - 1 -
1T 312 675 1 Guide rod x x - 3 -
Outlet piston 1T 310 284 1 Piston to scalding group complete x x 2 2 -
1T 310 233 1 Sieve upper piston x x 2 1 -
1T 310 382 1 O-Ring Silicon 36,09 x 3,53 x x 1 1 -
1T 310 234 1 Clamping ring for upper piston x x 2 1 -
Preventive Maintenance Evolution
Work
TD-102395.xlsx B 1 / 3
