Franke Evolution User Manual

1 = Replace
2 = Clean; control (replace when needed)
3 = Visual inspection; adjust (replace when needed) 6 Mth. 12 Mth. 36 Mth.
Group Article Amount Description Basic Top /20000 /40000 /120000
Work
1T 310 027 1 Valve-mains Y33 x x - - 3
1T 310 011 1 Metallic hose x x - - 1
1L 297 307 2 Seal 3/8 x x - - 1
1H 326 125 1 Pump double supported x x - 3 1
1T 311 826 1 Non return valve x x - 3 1
BK 310 765 1 Pumpbypass E/EII/G Fluid O Tec x x - 2 -
10 296 083 1 Flowmeter x x - 2 2
1L 296 311 1 O-Ring x x - 2 1
BK 312 606 1 Pressure control valve 12 bar Evo. x x - 1 1
1T 311 454 1 Coldwater valve bloc ODE x x - 3 2
BK 311 488 3 Plunger ODE 2/2 way x x - 3 2
1T 310 132 4 Fast coupling x x - 3 2
1Y 320 087 2 Push-in coupling x x - 3 2
1Y 320 408 1 Orifice d=4x0.8 black x x - 2 1
1Y 320 409 2 Orifice 0.6mm for Hose 2mm x x - 2 1
1Y 320 535 1 Orifice 0.4mm for hose 2mm blue x x - 2 1
1T 311 453 1 Hotwater valveblock ODE x x - 2 1
BK 311 489 1 Plunger ODE 3/2 x x - 2 -
BK 311 488 3 Plunger ODE 2/2 way x x - 2 -
1T 310 132 3 Fast coupling x x - 3 1
1T 312 654 1 Vacuum valve x x 3 1 1
Brew valve 1T 310 025 1 Valve 3/2 Typ 219 24V DC 12W x x - 1 1
By- pass valve 1T 310 023 1 Valve 24V DC (8W) Y4, Y6, Y5,Y30 x - 3 2
Grinder BK 325 971 1 Ceramic grinding wheel kit x x - 3 1
Hot water-
valve block
Cold water-
valve block
Water flow-
Valves
TD-102395.xlsx B 2 / 3

Franke Evolution Specifications

General

Power Supply	220-240 V
Water Supply	Tank
Water Connection	No
Material	Stainless Steel
Programs	Espresso, Coffee, Cappuccino, Latte Macchiato, Hot Water
Display	Yes
Milk System	Integrated
