1 = Replace
2 = Clean; control (replace when needed)
3 = Visual inspection; adjust (replace when needed) 6 Mth. 12 Mth. 36 Mth.
Group Article Amount Description Basic Top /20000 /40000 /120000
Work
Milk system
CF2 1Y 320 536 1 Orifice 0.4mm for hose 4mm blue x x 2 2 1
CF2 BK 310 958 1 Flow control valve x x 2 1 1
CF2 1T 310 621 1 Coupling x x 2 2 1
CF 1Y 320 546 2 Connector black XFMS zu Milch 200 x x 2 2 1
CF BK 320 687 1 Coupling half w. non return valve x x 2 2 1
CF 1H 326 168 1 Non return valve outlet x x 2 1 -
CF 1Y 320 473 1 Orifice 0.6mm for Hose 4mm x x 2 2 1
CF 1H 326 386 1 Milk pump with plug Gotec x x 3 3 1
1L 296 485 1 Silicone hose ID= 3 mm x x 1 1 1
1T 310 489 1 Y distributor x x - 2 1
1Y 320 211 1 Squeezd tube valve 24V DC x x 3 3 3
1T 310 623 1 Reduction x x 2 2 1
1T 310 622 3 Seal cone x x 2 1 1
1T 310 644 2 Spring to Milksystem x x 2 1 1
BK 310 192 2 O-Ring D=8,73x1,78 x x 2 1 1
1T 310 618 2 Body for double safety valve for sy x x 2 2 1
1T 310 645 2 O-Ring 4x1mm x x 2 1 1
02 296 519 1 Lock washer d=3.2 x x 2 1 1
1L 301 007 2 O-Ring 6.07x1.78 to outlet x x 2 1 1
1L 301 010 2 Coupling half to outlet x x 2 1 1
1T 310 624 1 Nozzle to Milksystem x x 2 1 1
single outlet 1T 310 646 1 O-Ring 26.7x1.78mm x x 2 1 1
double outlet 1L 301 433 1 O-Ring 37,82x1,78 x x 2 1 1
Outlet 1Y 320 447 1 Coffee outlet x x 2 2 1
1L 296 485 1 Silicone hose ID= 3 mm x x 1 1 1
1L 301 010 1 Coupling half to outlet x x 2 1 1
1L 301 007 1 O-Ring 6.07x1.78 to outlet x x 2 1 1
1T 310 489 1 Y distributor x 2 1 1
Hose 1L 296 337 1 Flexilon - hose x x - 2 1
1T 310 138 1 Hose teflon 6x4mm x x - 2 1
expendure of time (hour) 1.5 * 4 * 6.5 *
*
The target data are approximate times it takes
a trained Franke service technician under normal conditions.
approx.
TD-102395.xlsx B 3 / 3
