Programming
Install Card
All of the Evolution settings can be programmed with the Install Card. Navigation is via the four function
keys as shown below. The card contains the chip for the machine and is inserted from below into the
card reader; the card must remain there while performing the settings. The first time a new card is used
the PIN code has to be entered and confirmed. The PIN code can be entered incorrectly a number of
times without it being disabled. If, however, you forget the PIN code, the card is unusable and must be
replaced. Once the entry has been confirmed, the card can be removed for 5 minutes without having to
re-enter the code; the programming displays the exited menu setting. The described settings can also be
made using the Service Tool. Only with the Service Tool, in the labelling foil editor, is it possible to label
the foils. (the Service Tool is described in separate instructions.)
1 The Clean button is used for entering a menu or submenu, for confirming an entry
(Enter / Save), and for moving to the next position when entering a number.
2/3 The -/+ button is used for making a selection in a menu. They are also used in a
submenu for increasing or decreasing a value to the desired setting as well as for
activating or deactivating a function.
4 The Exit button is used to leaving a menu or submenu/setting without saving.
Symbols appearing in the display
+ *
