Franke Kaffeemaschinen AG
TD-100228 A.doc page 4 / 33
Install Menu 4 - 9
4 Fluid-System
5 Show Counter
6 Clear Counters
1 Pressure adjustm. 1 Machine total 1 Cycles piston
2 Emptying 2 Cycles piston 2 Waterquantity
3 Waterquantity 3 Grinder left
4 Grinder left 4 Grinder right
5 Grinder right 5 Coffeeprod. total
6 Number of clean. 6 Milkproducts
7 Coffeeprod. total 7 Waterprod. total
8 Milkproducts 8 Service
9 Waterprod. total
10 Productcounter
11 Service
7 Check Outputs
8 Check Inputs
9 Card service
1 K3 Coffee 1 Temp. coffee 1 Change pin-code
2 K2 HW / steam 2 Temp. auto-steam 2 Adjust clear
3 K7 Water pump 3 Temp. hot water 3 Delete Download
4 K6 Grinder left 4 Flowmeter 4 Simulate Grinder
5 K4 Grinder right 5 Level
6 Y4’ V CW mix 6 Current BU-motor
7 Y5 V feed 7 Choco Input 1
8 Y3 V breakfast 8 Choco Input 2
9 Y30 Cappu clean. 9 Water tank
10 Y31/37 Cappu air 10 Door
11 Y20 Cappu steam 11 Coffee outlet
12 Y33 V Water main 12 Pressure switch
13 Y4 Tea valve 13 Piston position
14 Y1 Brew valve 14
15 Y6 Steam valve 1 15 Supervision cup
16 Y6’ Steam valve 2 16 Milk level
17 Milk Bit 1
18 Milk Bit 2
19 Choco out 1
20 Choco out 2
To Next Page
