(10) Parting agent nebuliser connection
for connecting to the parting agent nebuliser; to supply the parting agent
nebuliser with compressed air
(11) Spray device connection
for connecting to the parting agent nebuliser; for spraying the com-
pressed air/parting agent mixture into the cleaning opening
If a parting agent nebuliser is not used, connect parting agent nebuliser
connection (10) to spray device connection (11). Use the supplied com-
pressed air connecting hose for this purpose.
(12) Wire cutter connection socket
for electrically controlling the wire cutter
(13) Dipping bowl with spill tray
NOTE!
Ensure that there is always sufficient parting agent in the dipping bowl when in
use (i.e., ensure that the fill level indicator never lights up).
NOTE!
If the dipping bowl is not in use, ensure that there are no parting agent residues
left in the bottom.
31
EN
