Fronius Robacta TC 1000 - Cleaning Program Sequence with Dipping Bowl

4
Ensure that not too much parting agent has accumulated on the gas nozzle
(no droplet formation). If this is the case:
-
Reduce the spray time or
-
After the cleaning operation, blow out the welding torch with com-
pressed air using the hosepack
Cleaning pro-
gram sequence
with dipping
bowl
Start "Welding torch
cleaning" program
Move to position A
Marker query
0 or 1
Move to position D
if marker = 0
Set 1
Wait 0.5 s
Set 2
Wait 0.5 s
Reset 1
Reset 2
Set marker 1
Move to position C
End
Set 1/Reset 1
Blow compressed air through torch
Set 2/Reset 2
"Start cleaning" signal
Move to position E
Set 1
Wait 0.5 s
Set 2
Wait 0.5 s
Reset 1
Reset 2
Set marker 0
Move to position C
Move to position B
Wait 1 - 4 s
Move to position A
Wait 1 - 4 s
Move to position C
if marker = 1
V
max
= 10 cm/s
(236.22 ipm)
