Troubleshooting 192
Clearing Paper Jams From the Optional 250-Sheet
Feeder
NOTE:
• To resolve the error displayed on the LCD panel, you must clear all print media from the print media path.
1 Pull the optional 250-sheet feeder out of the printer carefully. Hold the feeder with both hands,
and remove it from the printer.
NOTE:
• Paper in the optional 250-sheet feeder feeds to the printer from the front of the standard 250-sheet tray,
therefore paper jammed in the standard 250-sheet tray can block the optional 250-sheet feeder in the
printer, preventing you from opening it. Look for the jammed paper sequentially, starting with the optional
250-sheet feeder.
2 Remove all jammed and/or creased paper from the feeder.
3 Pull the jammed paper out carefully to avoid tearing it. If you cannot remove the paper, go to the
next step to remove the jammed paper from the inside of the printer.
4 Push the side button to open the front cover.
To Next Page
