247 Maintenance
Cleaning Inside the Printer
Clean the feed roller inside the printer if print media does not feed correctly.
1 Turn off the printer and disconnect the power cord.
2 Pull the standard 250-sheet tray out of the printer about 200 mm. Hold the standard 250-sheet
tray with both hands, and remove it from the printer.
3 Push the side button to open the front cover.
4 Open the belt unit.
5 Turn the four drum cartridge lock levers 90-degrees counterclockwise.
To Next Page
