109
4.4 Cleaning the Rollers (with a lint-free cloth)
4
DAILY CARE
11. Clean the Feed rollers (metal rollers, each set consists of 2 rollers, 9
locations) on the upper side of the lower transport path using a lint-free
cloth moistened with the cleaner F2.
Take care especially to remove black stains on the rollers, since such stains are deteriorating the
feeding performance.
12. Clean the Pinch rollers (rubber rollers, each set consists of 2 rollers, 9
locations) on the upper side of the upper transport path using a lint-free
cloth moistened with the cleaner F1 or isopropyl alcohol.
13. Close the ADF cover.
For details, refer to “2.3 Opening and Closing ADF” on page 12
ATTENTION
Do not use the cleaner F2 for any other parts. Use it only for cleaning the
Feed rollers.
Feed rollers
Pinch roller
To Next Page
