8.4 Multifeed Detection
Setting Example 1:
Specified area = Right
, Selected mode = Non-detection area, Start = 50mm, End = 200mm
Setting Example 2:
Specified area = Middle
, Selected mode = Detection area, Start = 50mm, End = 200mm
HINT
When you want to detect overlapping, be sure that paper documents are not
clinging to each other. Those clinging documents (glued or with static cling)
may cause a lower multifeed-detection ratio.
35
35
35
60
60
50
200
Feeding direction
Unit: mm
35
35
35
60
60
50
200
Feeding direction
Unit: mm
