Technical data
Technical data
Electrical data
Protection class: II
Rated voltage range 100 – 240 V
Rated frequency 50 – 60 Hz (AC)
Max. rated current 1.5 – 0.8 A
Dimensions
Width/depth/height: ESPRIMO Q956/Q957:
186 m m x 191 mm x 59 mm /
7.32” x 7.49” x 2.30”
ESPRIMO Q55x/Q958:
185 m m x 190 mm x 54 mm /
7.28” x 7.48” x 2.13”
Weight
in basic configuration: approx. 1.8 kg / 4.0 lbs
Ambient conditions
Environment class: 3K2
Environment class: 2K2
DIN EN 60721-3-3
DIN EN 60721-3-2
Temperature
Operation (3K2) 15 °C .... 35 °C / 59 °F ... 95 ° F
Transport ( 2 K2) –25 °C .... 60 °C / –13 °F ... 140 °F
The formation of condensation is not permitted while the device is in operation!
Supply areas and clearances required to ensure ad equate ventilation:
without air vents
with air vents
min. 10 mm / 0.39 inch
min. 200 m m / 7.87 inches (exception: underside
in vertical operating position, refer to "
Setting up
the device", Page 20)
The data sheets of these devices provide detailed te chnical data. The data sheets
are available on the Internet at "
http://www.fujitsu.com/fts/".
