Ports and Operating Elements
Rear
FUJITSU Desktop ESPRIMO Q556
5 6
14 13 12 10 9
1
711 8
3 42
1 = Latching clip (optional)
2 = Top casing cover unlocking mechanism
3 = Security lock device
4 = Padlock clamp
5 = LAN port
6 = PS/2 port
7 = Audio output
8 = 2 USB ports (USB 3.1)
9 = 2 USB ports (USB 2.0)
10 = Display port
11 = Bottom casing cover unlocking mechanism
12 = DVI-D monitor port
13 = Serial port
14 = Mains connection (AC IN)
12 Fujitsu
