B
A
Screw
Circular hole sections
REAR
interfere. If it interferes, slide the cable support toward the chassis while
holding the latches (B in Figure 3-54) of the left and right cable support
brackets. The cable support should be in the position nearest the chassis, with
the cable support bracket latches engaged.
f. If the cable support
interferes with the door even when you slide it toward the
chassis as far as possible, remove the cable support.
Figure 3-54
Attaching the cable support brackets
Chapter 3 Installing the System 115
