FRONT
REAR
2U top
1U top
1U bottom
Mounting
area (2U)
Mounting
area (2U)
Attach
the
rail
such
that
the
spring-loaded
side
(B
in
Figure
3-70)
faces
the
front
and
the
flange
(C
in
Figure
3-70)
faces
the
bottom.
a.
From
the
front
of
the
rack,
insert
the
rail
protrusions
into
2U
top
and
1U
top
in
the
front
supporting
column
of
the
rack.
b.
Pull
out
the
rail
to
as
far
as
the
depth
of
the
rack.
c.
Insert
the
rail
protrusions
into
2U
top
and
1U
bottom
in
the
rear
supporting
column
of
the
rack.
d.
Secure
the
rail
with
one
M6
screw
to
the
front
supporting
column
of
the
rack.
The
fixing
location
is
2U
bottom.
e.
Attach
the
other
rail
in
the
same
manner.
Figure
3-72
怀怀
Attaching
the
Type-1
rail:
Locations
of
protrusions
-
For
the
Type-2
rail
The
letter
[R]
on
a
side
of
a
rail
indicates
that
the
side
is
the
front
right
side,
and
[L]
indicates
that
the
side
is
the
front
left
side.
a.
From
the
rear
of
the
rack,
insert
the
rail
protrusion
into
1U
top
in
the
front
supporting
column
of
the
rack.
b.
Pull
out
the
rail
to
as
far
as
the
depth
of
the
rack.
c.
Insert
the
rail
protrusion
into
2U
top
in
the
rear
supporting
column
of
the
rack.
d.
Secure
the
rail
with
one
M6
screw
to
the
front
supporting
column
of
the
rack.
The
fixing
location
is
2U
bottom.
e.
Attach
the
other
rail
in
the
same
manner.
Chapter
3
怀
Installing
the
System 127
