Fujitsu M10 User Manual

C
REAR
(M3 screws)
REAR
Circular
hole sections
D
Figure 3-85
Attaching the cable support
●
For the Type-2 cable support
a. Tilt the cable support to align the circular holes at the rear of the groove with
the two screws of a cable support fixing bracket (D in Figure 3-86), and attach it.
Level the cable support. Then, align the circular holes at the other side
with the
two screws, and attach it.
Figure 3-86
Attaching the cable support (1)
Chapter 3 Installing the System 137
