Table 3-7
Reference: List of accessories for expansion rack 1
Number
in figure
Name Quantity Remarks
1 to 3PDU power cord (for connecting PDU and
customer facilities)
8 or 6(*1)
4Binding band 8
5 Hook-and-loop fastener strip 1 set
6Cage nut attachment tool 1
7Key (for both front and rear doors) 2
8Cable holder (F) 10
9Cable holder (R) 2
10 M5 flat-head screw (for attaching cable holder) 12
11 M5 core spring nut (for attaching cable holder) 12
12 Protection bushing (for
top cover opening) 3
*1 Eight cables are supplied for the single-phase power supply, and six cables for the three-phase power supply.
Table 3-8
Reference: List of accessories for expansion rack 2
Number
in figure
Name Quantity Remarks
1 to 3PDU power cord (for connecting PDU and
customer facilities)
8 or 6(*1)
4Binding band 8
5 Hook-and-loop fastener strip 1 set
6Cage nut attachment tool 1
7Key (for both front and rear doors) 2
8Cable holder (F) 10
9Cable holder (R) 2
10 M5 flat-head screw (for attaching cable holder) 12
11 M5 core spring nut (for attaching cable holder) 12
12 Protection bushing (for
top cover opening) 3
13 Crossbar unit 2(*2)
unit through a crossbar box. Dedicated power distribution units (PDUs) for
supplying power, crossbar boxes, crossbar cables, and XSCF cables are mounted as
standard in the expansion rack.
The expansion racks are expansion rack 1 and expansion rack 2. Expansion rack 1 is
used for configurations up to the 8BB configuration.
Expansion rack 2 is used for the
9BB to 16BB configurations.
Table 3-7, Table 3-8, and Table 3-9 below list the components of the expansion racks.
Fujitsu M10/SPARC M10 Systems Installation Guide
･
July 201572
