RX200 S3 Operating Manual 13
Introduction Technical data
Mechanical values
Weight
Approx. 17 - 18 kg (depending on configuration)
Ventilation clearance
At least 200 mm on the front and on the rear side
Environmental conditions
Condensation must be avoided during operation.
Noise level
Width (without front panel) 430 mm
Installation depth 729 mm
Total depth (with front panel) 773 mm
Height 43 mm or 1 HU
Environment class 3K2
Environment class 2K2
EN 60721 Part 3-3
EN 60721 Part 3-2
Temperature:
Operation (3K2)
Transport (2K2)
5 °C ... 35 °C
- 25 °C ... 60 °C
Humidity 10% ... 85%
Sound power level L
WAd
(ISO 9296) ≤ 6.7 B (standby)
≤ 7.5 B (operating)
Sound pressure level at bystander position
L
pAm
(ISO 9296)
≤ 50 dB (A) (standby)
≤ 58 dB (A) (operating)
