Fujitsu PRIMERGY RX200 S3 User Manual

40 Operating Manual RX200 S3
Installing/Removing the Server in/from the Rack Hardware Installation
Figure 7: Inserting the server
V CAUTION!
At least two people are needed to position the server in the rack.
Ê Push the prepared server into the rails that are attached to the rack until the
server rails engage.
I Ensure that the server is inserted horizontally and is not tilted.
Ê Press the safety springs in on both sides (2).
Ê Gently push the server as far as it will go into the rack (3).
Ê Fasten the server to the rack (4) using the two knurled screws (front panel).
To remove the server, follow this procedure in reverse.
1
2
3
4
4

Fujitsu PRIMERGY RX200 S3 Specifications

General

Number of Processors	2
Storage	Up to 6 x 3.5" SAS/SATA HDD
RAID Support	RAID 0, 1
Network	Dual Gigabit Ethernet
Form Factor	1U Rack
Power Supply	Hot-plug redundant power supply
