TX150 S6
Options Guide
23
Preparation
Floorstan
d model
Figure 5: Loosening the lower hooks
Ê
Push the drive c
over upward (1).
Ê
Press the two touch points
of the lower hooks (2+3) inward and pull out the
front cov
er s
idew
ard (4)
.
2
3
4
1
22
24
