24 Options Guide TX150 S6
Floorstand model Preparation
4.1.3 Removing the hard disk cover
The hard disk cover has to be removed before installing further hard disk drives:
Ê Exit all applications and shut down the server properly.
Ê Press the On/Off button if the server has not been switched off by the
operating system.
Figure 6: Removing the hard disk cover
Ê Unlock the server (1) and remove the key.
Ê Push the drive cover up as far as possible (2).
Ê Remove the hard disk cover (3 + 4).
1
2
3
4
