86 Options Guide TX150 S6
Floorstand model Completion
13.1.2 Attaching the front cover
After you have installed further accessible drives, reattach the front cover.
Figure 69: Attaching the front cover
Ê Press the three hooks (1) on the right side in the recesses of the housing.
Ê Press the front cover onto the housing (2) until the three tabs on the left side
engage (3).
Ê Attach the hard disk cover as shown in figure 68 on page 85.
1
3
2
