TX150 S6 Options Guide 63
9 SATA SW RAID
V CAUTION!
Follow the safety instructions in the chapter “Safety instructions” on
page 15 et seq..
The SATA SW RAID 5 functionality will be activated by installing a license key
(RAID key).
9.1 Inserting the RAID key
Ê Open the server as described in the chapter “Preparation” on page 21 et
seq..
Figure 46: Inserting the RAID key
Ê Insert the RAID key in the round socket on the system board (see Technical
Manual for the system board D2559).
Ê Close the server, connect it to the power outlet, and switch it on as described
in the chapter “Completion” on page 85 et seq..
